Full-bridge DMOS PWM motor driver IC
02/08/2012 Allegro Microsystems Europe Ltd
- Extended temperature version for automotive HVAC systems -An automotive version of the A4950 full-bridge motor driver IC is now available from Allegro MicroSystems Europe. The A4950 is designed for pulse width modulated (PWM) control of DC motors, and is capable of peak output currents to ±3.5 A and operating voltages to 40 V. The device is AECQ100 Grade 1 qualified and is rated over an extended ambient operating temperature range of -40°C to 125°C.
The new device is tested across extended temperature and voltage ranges to ensure compliance in both automotive and industrial applications, and is particularly suited to use in automotive HVAC systems.
A simple logic interface is available to control the speed and direction of a DC motor with externally applied PWM control signals. Internal synchronous rectification control circuitry is provided to reduce the power dissipation during PWM operation.
Internal circuit protection includes overcurrent protection, motor-lead short-circuit to ground or supply, thermal shutdown with hysteresis, undervoltage monitoring of load supply voltage, and crossover current protection.
The A4950 is supplied in a low-profile 8-pin SOICN package with exposed thermal pad (suffix LJ) that is lead (Pb) free, with 100% matt tin leadframe plating.
Please click here to download a copy of the data sheet.
For further information please contact:
Allegro MicroSystems Europe Ltd
Melita House
124 Bridge Road
Chertsey
Surrey
KT16 8LH
Tel: +33 (0) 4 50512359
Fax: +33 (0) 4 505 12083
mailto:allegroeurope@allegromicro.com
http://www.allegromicro.com
