Motion29 Launches Bircher Reglomat ES Gate Safety Switching Unit
24/05/2011 Motion 29 Limited
Evaluates safety edges and contact mats for maximum machinery safetyMotion29 announces the introduction of the new Bircher Reglomat ES Gate Safety switching device to their existing range of industrial engineering solutions. Designed to accurately monitor safety edges and mats, the user-friendly unit can be configured to suit a whole host of different applications and situations.
The simple two-channel system and straightforward LCD display make the set up and operation of the device rapid and simple. Additional measuring instruments are unnecessary as the ES Gate Unit clearly displays the resistance values of the connected safety elements. Whenever a safety edge is triggered, the signal is immediately conveyed on the LCD display to show at a glance which safety edge and which output is affected.
The intelligent software behind the compact device allows for great flexibility in its function and can be easily re-configured to suit the required application. The ES Gate unit is the newest development in the proven ES technology range, and is specifically designed to complement and safeguard the latest technologies in automated machinery. Approved to EN 12978 and EN ISO 13849-1 standards.
Application example: A milling or grinding machine with automatic protective door
Solution: Protect the closing edge with a safety edge and EsGate 3 safety switching device
Summary of benefits:
· Wide range of applications
· True two-channel system
· Simple and rapid set up
· Clear LCD display - readable at a glance
· Lightweight (200g) and compact (W22.5 × H94 × D90 mm)
· Bridging resistors not needed at inputs
· No need for additional measuring instruments
For stockist details: www.motion29.com T:08450 942510.
