New and improved igus chainflex cables
30/07/2014 igus UK Ltd
Energy chain and cable specialist igus has expanded and improved its chainflex CF211 and CF111.D series of measuring cables developed for dynamic equipment applications. The cables feature an enhanced core and shield structure that offers a much longer service life and makes them easier to install, reducing assembly times by as much as 30%.Specifically for use in analogue and digital measuring systems, such as DRIVE-CLiQ*, igus offers the CF211.028, CF111.028.D and CF113.028.D - each representing a different level of mechanical properties.
The CF211 has a PVC outer jacket, which allows a range of operating temperatures from -5 to +70 degC; it is well-suited to applications in warehouse storage and handling systems, processing tools and packaging machines. The CF111.D features a halogen-free, flame-resistant PUR outer jacket; this cable is specially designed for short travel applications. At the high-end, the CF113.D boasts a PUR inner jacket and an extremely bend resistant braiding of tinned copper wires with an optical coverage of 90%; this cable structure is ideal for use in fast, handling, clean room and low temperature applications down to -20degC.
The CF211 and CF111.D series comes in a variety of sizes and follow the DESINA colour coding. igus' chainflex cables also conform to, and are in accordance with, various cable industry standards. Like all other igus chainflex cables, the CF111, CF111.D and CF113.D data cables are available ex-stock within 24 hours or the same day, without cutting costs or minimum order quantity.
For more information, please contact:
igus®
Caswell Road
Brackmills
Northampton
NN4 7PW
Tel: +44 (0)1604 677240
Fax: +44 (0)1604 677245
Email: sales@igus.co.uk
Web: www.igus.co.uk
