The new M4 ISO FX piping isometric software converts PCF files into piping isometrics and offers substantial time savings.

M4 ISO FX generates piping isometrics, parts lists and other important documentation in a matter of seconds, completely standalone from your CAD system. The process is fully automated which means manual effort is no longer required.

PCF is a common format supported by most professional 3D pipework design systems. The PCF formal enables pipework design data to be accurately exchanged between different systems. M4 ISO FX imports pipework design data from PCF files and uses it to automatically generate fully dimensioned piping isometric drawings. The layout of the generated isometrics is determined by highly-configurable style templates which can be adapted to meet specific company requirements.

Generating piping isometrics simply and quickly

M4 ISO FX is the easiest and fastest way to create piping isometric drawings. Isometrics, together with parts lists and other types of listing can be generated in the required style in seconds, at the push of a button. Piping isometrics are production-ready documents that can be used directly for pipework fabrication and documentation purposes without delay. M4 ISO FX is a standalone software package that is installed independently of other CAD systems. M4ISO FX fully automates the piping isometric generation process, making it a great asset for any company looking to maximise efficiency while minimising costs.

Try M4 ISO FX today

M4 ISO FX can be downloaded directly from the CAD Schroer website for a free 30-day trial. You can use it generate up to 50 piping isometric drawings during the 30-day trial period. CAD Schroer also offers free technical support throughout the trial.

Try M4 ISO FX for free >>
