With Eaton's New Gateway, SmartWire-DT Communicates with Sercos
28/03/2017 Eaton Electric Sales Ltd
Eaton is adding a new gateway to SmartWire-DT, the power management company's intelligent wiring and communication system, which enables machine and system builders to easily interface with Sercos III fieldbus systems. The EU5C-SWD-Sercos gateway is the latest product to result from the cooperation with Hilscher Gesellschaft für Systemautomation, a global manufacturer and service provider for communication solutions and automation based in Hattersheim, Germany.With the introduction of the new gateway, SmartWire-DT supports not only the Profibus-DP, CANopen, Modbus-TCP, Ethernet/IP, Profinet, Powerlink and EtherCAT fieldbus protocols, but also Sercos III. This protocol supports demanding industrial automation applications, such as packaging machines, where high performance and real-time capabilities are necessary.
Machine and system builders in these fields can now benefit from the advantages that the SmartWire-DT device-level based intelligent wiring system offers. These include significantly reduced wiring time as well as reduced engineering, commissioning and maintenance effort.
The portfolio of SmartWire-DT components ranges from pilot devices, contactors, motor starters, soft starters, variable speed starters and frequency inverters to circuit breakers and HMI/PLCs. For applications that involve digital and analogue process data outside the cabinet, Eaton offers IP67 I/O SmartWire-DT modules that connect single sensors in the machine periphery over a length of up to 600 m.
The gateway transfers data from connected SmartWire-DT devices via the Sercos protocol to the installation's PLC or other controller. It can transfer up to 1,000 bytes of input and output data, from a maximum, 99 devices in cyclical operation and also supports acyclical communication. As well as the 100 Mbit switch for Sercos communication, the gateway has a USB interface for routine diagnostics.
The gateway is configured in the same way as other Sercos devices by using a standard ESI description file that is incorporated in the programming system. Individual SmartWire-DT modules are selected and parameterised in the normal way.
For planning, configuring and commissioning SmartWire-DT networks, Eaton offers its well-proven SWD-Assist software. With the configuration tool, users can select any device in the system with just a few mouse clicks, and a software wizard is provided that enables the configuration to be checked quickly and easily.
All of the connected SmartWire-DT devices can be commissioned via the gateway's diagnostic interface, which means that commissioning can be completed quickly and conveniently without the need to connect the PLC.
SmartWire-DT devices have CE, UL and CSA approvals, making them suitable for use worldwide.
For more information, please contact:
Eaton Information Response Service
Grimshaw Lane
Middleton
Manchester
M24 1GQ
Tel: +44 (0) 8700 545 333
Email: Literature-InfoUK@Eaton.com
web: www.eaton.com
